·Total Operating Stroke: 20mm±0.5
·Operating Force: 50∼350gf
·Power Rating: 0.06W(Linear Taper:B) 0.03W(Other Taper)
·Voltage Rating: 150V(Linear Taper:B) 100V(Other Taper)
·Resistance Rating: 5KΩ∼500KΩ
·With center Click Available
·Insulated Lever and Metal lever Type Available
·Flux counter measure is Taken Through Outsert Molding Around the Resistor
·L: Type of Lever Reference

·Total Operating Stroke: 20mm±0.5
·Operating Force: 50∼350gf
·Power Rating: 0.06W(Linear Taper:B) 0.03W(Other Taper)
·Voltage Rating: 150V(Linear Taper:B) 100V(Other Taper)
·Resistance Rating: 5KΩ∼500KΩ
·With center Click Available
·Insulated Lever and Metal lever Type Available
·Flux counter measure is Taken Through Outsert Molding Around the Resistor
·L: Type of Lever Reference

·Total Operating Stroke : 300mm±0.5
·Operating Force : 50∼350gf
·Power Rating : 0.1(Linear Taper:B) 0.05W(Other Typer)
·Voltage Rating : 200V(Linear Taper:B) 150V(Other Typer)
·Resistance Rating: 5KΩ∼500KΩ
·With center Click Available
·Insulated Lever and Metal lever Type Available
·Flux counter measure is Taken Through Outsert Molding Around the Resistor
·L: Type of Lever Reference

·Total Operating Stroke : 300mm±0.5
·Operating Force : 50∼350gf
·Power Rating : 0.1(Linear Taper:B) 0.05W(Other Typer)
·Voltage Rating : 200V(Linear Taper:B) 150V(Other Typer)
·Resistance Rating: 5KΩ∼500KΩ
·With center Click Available
·Insulated Lever and Metal lever Type Available
·Flux counter measure is Taken Through Outsert Molding Around the Resistor
·L: Type of Lever Reference
