1. Rating: DC 0.3A,30V
2. Contact Resistance: ?0.03Ω
3. Insulation Resistance: ?100MΩ
4. Withstand voltang: 500V AC/1 min
5. Service life: 5,000cycles

1. Rating: DC 0.3A,30V
2. Contact Resistance: ?0.03Ω
3. Insulation Resistance: ?100MΩ
4. Withstand voltang: 500V AC/1 min
5. Service life: 5,000cycles

1. Rating: DC 0.3A,30V
2. Contact Resistance: ?0.03Ω
3. Insulation Resistance: ?100MΩ
4. Withstand voltang: 500V AC/1 min
5. Service life: 5,000cycles

1. Rating: DC 0.3A,30V
2. Contact Resistance: ?0.03Ω
3. Insulation Resistance: ?100MΩ
4. Withstand voltang: 500V AC/1 min
5. Service life: 5,000cycles

1. Rating: DC 0.3A,30V
2. Contact Resistance: ?0.03Ω
3. Insulation Resistance: ?100MΩ
4. Withstand voltang: 500V AC/1 min
5. Service life: 5,000cycles
